Chapter 1 - Introduction to NetX Duo SNMP

The Simple Network Management Protocol (SNMP) is a protocol designed for managing devices on the internet. SNMP is a protocol that utilizes the connectionless User Datagram Protocol (UDP) services to perform its management function. The NetX Duo SNMP implementation is that of an SNMP Agent. An agent is responsible for responding to SNMP Manager's commands and sending event driven traps.

NetX Duo SNMP supports both IPv4 and IPv6 communication with SNMP Managers. NetX SNMP applications should compile and run in NetX Duo SNMP. However, the developer is encouraged to port existing SNMP applications to using the equivalent "duo" services. For example, when sending SNMP trap messages, the following 'duo' services should replace their NetX equivalent:

nxd_snmp_object_trap_send

nxd_snmp_object_trapv2_send

nxd_snmp_object_trapv3_send

For more details, see Description of SNMP Agent Services elsewhere in this User Guide for more details.

NetX Duo SNMP Agent Requirements

The NetX Duo SNMP package requires that an IP instance has already been created. In addition, UDP must be enabled on that same IP instance.

The NetX Duo SNMP Agent has several additional requirements. First, it requires access to port 161 for handling all SNMP manager requests. It also requires access to port 162 for sending trap messages to the Manager.

To use NetX Duo SNMP Agent with over IPv6 and to obtain IPv6 objects, IPv6 must be enabled in NetX Duo. See the NetX Duo User Guide for details on enabling the IP instance for IPv6 services.

NetX Duo SNMP Constraints

The NetX Duo SNMP protocol implements SNMP Version 1, 2, and 3. The SNMPv3 implementation supports MD5 and SHA authentication, and DES encryption. This version of the NetX Duo SNMP Agent has the following constraints:

1. One SNMP Agent per NetX Duo IP Instance
2. No support for RMON
3. SNMP v3 Inform messages are not supported
4. OPAQUE and NSAP data types are not supported
5. IPv6 addresses are defined as octet strings, and format checking is left to the application.

SNMP Object Names

The SNMP protocol is designed to manage devices on the internet. To accomplish this, each SNMP managed device has a set of objects that are defined by the Structure of Management Information (SMI) as defined by RFC 1155. The structure is a hierarchical tree type of structure that looks like the following:

Each node in the tree is an object. The "dod" object in the tree is identified by the notation 1.3.6, while the "internet" object in the tree is identified by the notation 1.3.6.1. All SNMP object names begin with the notation 1.3.6.

An SNMP Manager uses this object notation to specify what object in the device it wishes to get or set. The NetX Duo SNMP Agent interprets such manager requests and provides mechanisms for the application to perform the requested operation.

SNMP Manager Requests

The SNMP has a simple mechanism for managing devices. There is a set of standard SNMP commands that are issued by the SNMP Manager to the SNMP device on port 161. The following shows some of the basic SNMP Manager commands:

These commands are encoded in the Abstract Syntax Notation One (ASN.1) format and reside in the payload of the UDP packet sent by the SNMP Manager. The NetX Duo SNMP Agent processes the request and then calls the corresponding handling routine specified in the nx_snmp_agent_create call.

NetX Duo SNMP Agent Traps

The NetX Duo SNMP Agent provides the ability to also alert an SNMP Manager of events asynchronously. This is done via an SNMP trap command. There is a unique API for each version of SNMP for sending traps to an SNMP Manager. By default, the traps are sent to the SNMP Manager on port 162.

The NetX Duo SNMP Agent provides separate security keys for SNMPv3 trap messages. To do so, the SNMP application must create a separate set of keys from those applied to responses to Manager requests. Trap security enables the SNMP Agent to use the same or different passwords for authentication and privacy. For more information on creating security keys, see NetX Duo SNMP Authentication and Encryption in the next section.

A list of standard SNMP trap variables is enumerated at the top of nxd_snmp.h:

To include these variables in the trap message, the trap_type input argument in nx_snmp_agent_trapv2_send (SNMPv2) or nx_snmp_agent_trapv3_send (SNMPv3) is set to the enumerated value of these variables. An example is shown below for SNMPv2 to notify the SNMP Manager of a cold start event:

UINT trap_type = NX_SNMP_TRAP_COLDSTART;

status = nx_snmp_agent_trapv2_send(&my_agent, MIB_IP_ADDRESS,
                                  (UCHAR *)"public", trap_type,
                                  tx_time_get(), NX_NULL);

To include proprietary variables in the trap message, the trap_type input argument is set to NX_SNMP_TRAP_CUSTOM and the trap list input argument contains the proprietary data. Note that the trap message will contain as the system up time (1.3.6.1.6.3.1.1.4.1.0). An example is shown below for SNMPv2:

NX_SNMP_TRAP_OBJECT trap_list[3];
NX_SNMP_OBJECT_DATA trap_data0;

    /* Load the data into the OBJECT. */
    nx_snmp_object_id_get((void*)"1.3.6.1.4.1.7428.1.3.2.0", &trap_data0);

    /* Update the Trap Object with the object and OID. */
    trap_list[0].nx_snmp_object_string_ptr = (UCHAR *)"1.3.6.1.6.3.1.1.4.0";
    trap_list[0].nx_snmp_object_data  = &trap_data0;

    /* Null terminate the trap list. */
    trap_list[1].nx_snmp_object_string_ptr = NX_NULL;

    status = nx_snmp_agent_trapv2_send(&my_agent, MIB_IP_ADDRESS,
                                      (UCHAR *)"trapduo",
                                      NX_SNMP_TRAP_CUSTOM,
                                      tx_time_get(), trap_list);

NetX Duo SNMP Authentication and Encryption

There are two flavors of authentication, namely basic and digest. Basic authentication is equivalent to a simple plain text username authentication found in many protocols. In SNMP basic authentication, the user simply verifies that the supplied username is valid for performing SNMP operations. Basic authentication is the only option for SNMP versions 1 and 2.

The main disadvantage of basic authentication is the username is transmitted in plain text. The SNMPv3 digest authentication addresses this problem by never transmitting the username in plain text. Instead, an algorithm is used to derive a 96-bit 'digest' from the username, context engine, and other information. The NetX Duo SNMP Agent supports both MD5 and SHA digest algorithms.

To enable authentication, the SNMP Agent must set its Context Engine ID using the nx_snmp_agent_context_engine_set service. The Context Engine ID is used in the creation of the authentication key.

Encryption of SNMPv3 data is available using the DES algorithm. Encryption requires that authentication be enabled (one cannot encrypt data without setting the authentication parameters).

To create authentication and privacy keys, the following API are used:

UINT  _nx_snmp_agent_md5_key_create(NX_SNMP_AGENT *agent_ptr,
                                    UCHAR *password, NX_SNMP_SECURITY_KEY
                                   *destination_key)

UINT  _nx_snmp_agent_sha_key_create(NX_SNMP_AGENT *agent_ptr,
                                    UCHAR *password, NX_SNMP_SECURITY_KEY
                                   *destination_key)

Next, the SNMP agent must be configured to use these keys. To register a key with the SNMP agent, the following API are used:

UINT  _nx_snmp_agent_authenticate_key_use(NX_SNMP_AGENT *agent_ptr,
                                          NX_SNMP_SECURITY_KEY *key)

UINT  _nx_snmp_agent_privacy_key_use(NX_SNMP_AGENT *agent_ptr,
                                    NX_SNMP_SECURITY_KEY *key)

Separate keys can be created for trap messages. To apply keys for trap messages the following API are available:

UINT  _nx_snmp_agent_auth_trap_key_use(NX_SNMP_AGENT *agent_ptr,
                                       NX_SNMP_SECURITY_KEY *key)

UINT  _nx_snmp_agent_priv_trap_key_use(NX_SNMP_AGENT *agent_ptr,
                                       NX_SNMP_SECURITY_KEY *key)

To disable authentication or encryption for response messages and sending traps, use these services with the key pointer input set to NULL.

NetX Duo SNMP Community Strings

The NetX Duo SNMP Agent supports both public and private community strings. The public string is set with the nx_snmp_agent _public_string_set service. The NetX Duo SNMP Agent private string is set using the nx_snmp_agent_private_string_set service.

NetX Duo SNMP Username Callback

The NetX Duo SNMP Agent package allows the application to specify (via the nx_snmp_agent_create call) a username callback that is called at the beginning of handling each SNMP Client request.

The callback routine provides the NetX Duo SNMP Agent with the username. If the supplied username is valid or if no username check is necessary for the responding to the request, the username callback should return the value of NX_SUCCESS. Otherwise, the routine should return NX_SNMP_ERROR to indicate the specified username is invalid.

The format of the application username callback routine is defined below:

UINT nx_snmp_agent_username_process(NX_SNMP_AGENT *agent_ptr,
                                    UCHAR *username);

The input parameters are defined as follows:

For SNMPv1 and SNMPv2/v2C sessions, the application will want to examine the community string on an incoming SNMP request to determine if the SNMP request has a valid community string. There are several services for the SNMP application to do this.

The SNMP application can inquire if the current SNMP Manager request is a GET (e.g. GET, GETNEXT, or GETBULK) or SET type of request using this service:

UINT nx_snmp_agent_request_get_type_test(NX_SNMP_AGENT *agent_ptr,
                                         UINT *is_get_type);

If the request is a GET type, the application will want to compare the input community string to the SNMP Agent's public string:

UINT nx_snmp_agent_public_string_test(NX_SNMP_AGENT *agent_ptr,
                                      UCHAR *username,
                                      UINT *is_public);

Similarly if the request is a SET type, the application will want to compare the input community string to the SNMP Agent's private string:

UINT nx_snmp_agent_private_string_test(NX_SNMP_AGENT *agent_ptr,
                                       UCHAR *username,
                                       UINT *is_private);

The is_public and is_private return values indicate respectively if the input community string is a valid public or private community string.

The return value of the username callback routine indicates if the username is valid. The value NX_SUCCESS is returned if the username is valid, or NX_SNMP_ERROR if the username is invalid.

NetX Duo SNMP Agent GET Callback

The application must set a callback routine for handling GET object requests from the SNMP Manager. The callback retrieves the value of the object specified in the request.

The application GET request callback routine is defined below:

UINT nx_snmp_agent_get_process(NX_SNMP_AGENT *agent_ptr,
                               UCHAR *object_requested,
                               NX_SNMP_OBJECT_DATA *object_data);

The input parameters are defined as follows:

Note: For octet strings, the object must be assigned the length so that the internal function knows how long the length is since the callback itself does not have a length argument:

object_data -> nx_snmp_object_octet_string_size = mib2_mib[i].length;

Since the type of data is not known to the GET callback, there is no need to check the data type. Length will not have any effect on numeric types or strings which are null delimited.

Then call the internal function:

status = mib2_mib[i].object_get_callback)
                   (mib2_mib[i].object_value_ptr, object_data);

If the callback function cannot find the requested object, the NX_SNMP_ERROR_NOSUCHNAME error code should be returned. If any other error is detected, the NX_SNMP_ERROR should be returned.

NetX Duo SNMP Agent GETNEXT Callback

The application must also set the callback routine for GETNEXT object requests from the SNMP Manager. The GETNEXT callback retrieves the value of the next object specified by the request.

The application GETNEXT request callback routine is defined below:

UINT nx_snmp_agent_getnext_process(NX_SNMP_AGENT *agent_ptr,
                                   UCHAR *object_requested,
                                   NX_SNMP_OBJECT_DATA *object_data);

The input parameters are defined as follows:

Same as is true for GET callbacks, objects with octet string data must be assigned the length so that the internal function knows how long the length is since the callback itself does not have a length argument:

object_data -> nx_snmp_object_octet_string_size = mib2_mib[i].length;

Since the type of data is not known to the GET callback, there is no need to check the data type. Length will not have any effect on numeric types or strings which are null delimited.

Then call the internal function:

status = mib2_mib[i].object_get_callback)
                   (mib2_mib[i].object_value_ptr, object_data);

If the callback function cannot find the requested object, the NX_SNMP_ERROR_NOSUCHNAME error code should be returned. If any other error is detected, the NX_SNMP_ERROR should be returned.

NetX Duo SNMP Agent SET Callback

The application should set the callback routine for handling SET object requests from the SNMP Manager. The SET callback sets the value of the object specified by the request.

The application SET request callback routine is defined below:

UINT nx_snmp_agent_set_process(NX_SNMP_AGENT *agent_ptr,
                               UCHAR *object_requested,
                               NX_SNMP_OBJECT_DATA *object_data);

The input parameters are defined as follows:

Note that for octet strings, the SET callback should update the MIB table with the length of the data since the SNMP Agent has parsed the data and knows the type and length:

if (object_data -> nx_snmp_object_data_type ==
                           NX_SNMP_ANS1_OCTET_STRING)
{
    mib2_mib[i].length =
        object_data -> nx_snmp_object_octet_string_size;
}

object_data -> nx_snmp_object_octet_string_size =
                                 mib2_mib[i].length;

If the callback function cannot find the requested object, the NX_SNMP_ERROR_NOSUCHNAME error code should be returned.

If the NetX Duo SNMP host has created private community strings, and the SNMP sender of the SET request does not have the matching private string, it may return an NX_SNMP_ERROR_NOACCESS error. If any other error is detected, the NX_SNMP_ERROR should be returned.

Note: Although NetX Duo SNMP Agent supplies an SNMP MIB database with the distribution, it is primarily for testing and development purposes. The developer will likely require a proprietary MIB database for a professional SNMP application.

Changing SNMP Version at Run Time

The SNMP Agent host can change SNMP version for each of the three versions at run time using the nx_snmp_agent_set_version service. The SNMP Agent is by default enabled for all three versions when the SNMP Agent is created in nx_snmp_agent_create. However, the application can limit that to a subset of all versions.

Note: If the configuration options NX_SNMP_DISABLE_V1, NX_SNMP_DISABLE_V2 and/or NX_SNMP_DISABLE_V3 are defined, this function will have no effect enabling the effected versions.

The SNMP Agent can retrieve the SNMP version of the latest SNMP packet received using the nx_snmp_agent_get_current_version service.

SNMPv3 Discovery

The SNMP Agent, if enabled for SNMPv3, will respond to discovery requests from the SNMP Manager. Such a request contains security parameter data with null values for Authoritative Engine ID, user name, boot count and boot time. Authentication parameters are not applied to the DISCOVERY message. The variable binding list in the request is empty (contains zero items). The SNMP agent responds with a zero boot time and count, and the variable binding list containing 1 item, usmStatsUnknownEngineIDs, which is the count of requests received with an unknown (null) engine ID. On the subsequent GETNEXT request from the Browser/Manager, the boot data and security parameters are filled in only if security is enabled. If so it will also send a NotInTime data update in the PDU. The security parameters, e.g. authentication prove the identity of the Agent to the Manager.

More detailed information on SNMPv3 authentication is available in RFC 3414 "User-based Security Model (USM) for version 3 of the Simple Network Management Protocol (SNMPv3)".

NetX Duo SNMP RFCs

NetX Duo SNMP is compliant with RFC1155, RFC1157, RFC1215, RFC1901, RFC1905, RFC1906, RFC1907, RFC1908, RFC2571, RFC2572, RFC2574, RFC2575, RFC 3414 and related RFCs.
